30W Fiber Laser Marker Engraving Machine with 200x200mm Marking Area | F-30W
Ship to
Regular price £3,299.99
Sale price £3,299.99 Regular price £4,319.99 Save £1,020
VAT included

Free Shipping within UK

Purchase on account for public institutions:
We give public institutions and authorities the opportunity to order machines on account. Please contact us via email at: support@omtechlaser.uk

Why you need this laser machine
Features
  • RAYCUS SOLID-STATE LASER: A world-class solid-state fiber laser provides advanced efficiency, stability, and durability. It’s ideal for applications with tight tolerances requiring extreme precision and boasts an MTTF of over 100,000 hours.
  • GALVO-TECH CONTROL: A high-speed galvanometric drive system reduces delays and improves your marking speed. Its extreme stability ensures quick scanning, engraving, and project turnaround.
  • PRECISION FIELD LENS: Our compact Fθ field lens uses an air-spaced design and protective anti-reflective coating to give you excellent throughput with less than 1% distortion.
  • ADVANCED WORKSPACE: This laser machine comes with a built-in workspace grid with removable positioning bars for precise material placement. It also supports an optional rotary axis (not included) to mark tubes, bottles, pipes, and other curved surfaces.
  • ADDITIONAL LASER GUIDANCE: Once properly adjusted, the external red dot locator calibrates with the laser's scanner to allow a quick and accurate laser focus setup.
  • MANUAL FOCUS: Quickly focus the galvanometer laser on various materials by rotating the focus-height wheel. Plus, the vertical supporting tower is equipped with a ruler for convenient focus height measurements.
  • EMERGENCY STOP: The E-Stop safety button immediately stops the machine in case of emergency.
Technical Specifications
  • Power: 30W
  • Laser Wavelength: 1064 nm
  • Cooling Method: Air Cooling
  • Laser Frequency: 30-60 kHz
  • Marking Speed: Max. 7,000 mm/s (depending on different lettering fonts and sizes)
  • Min. Marking Depth: 0.05 mm
  • Min. Line Width: 0.15 mm
  • Accuracy: ±0.1 μm
  • Lifetime: 100,000 hours
  • Laser Source: Raycus
  • Galvanometer Source: Galvo-Tech
  • Operating Software: EzCad2
Package List
  • 1 x Fiber Laser Marker Machine
  • 1 x Monitor Mount
  • 1 x USB Cable
  • 1 x Power Cable
  • 1 x Foot Pedal
  • 1 x Laser Safety Glasses
  • 1 x Grounding Wire
  • 10 x Hex Wrenches
  • 1 x USB Flash Drive
  • 1 x Measuring Tape
  • 1 x Accessory Bag
  • 2 x Clips
  • 4 x Bolts
  • 1 x Instruction Manual
