50W CO2 Polar Desktop Laser Engraving Machine with 510x300 mm Engraving Area | OMTech Polar

OMTech polar desktop CO2 laser engraver
£2,399.99
£2,399.99 £3,119.99 Save£720
VAT included
Get FREE LightBurn+Laser Alignment Tool+Birch Plywood
0
Days
0
Hours
0
Mins
0
Secs
shipping logo

Free shipping within UK mainland

Quantity
OMTech polar desktop CO2 laser engraver
50W CO2 Polar Desktop Laser Engraving Machine with 510x300 mm Engraving Area | OMTech Polar

Free shipping within UK mainland

£2,399.99
£2,399.99 £3,119.99 Save£720

Recommended software:
LightBurn software

Purchase on account for public institutions:
We give public institutions the opportunity to order machines on account. Please contact us via email at: support@omtechlaser.uk

omtech desktop polar laser engraver OMTech desktop 50W polar
OMTech Compact polar Desktop Laser
Compact Desktop Laser
OMTech Polar stands out with its compact dimensions (970 x 565 x 234 mm) and a low net weight of 47 kg. Despite being 80% smaller in volume compared to conventional 50W machines, it offers the same working area. The integrated cooling system minimizes space requirements - ideal for limited spaces.
OMTech Powerful 50W Polar
At the heart of OMTech Polar is a robust 50W laser, with a lightning-fast engraving speed of up to 500 mm/s. It can effortlessly cut through walnut up to 15 mm thick and acrylic up to 20 mm thick, to meet your requirements.
360-Degree Panoramic Integrated Camera
Polar Laser enables a quick preview by overlaying the engraving design on the real-time display of the engraved object. After pressing the start button, the Polar automatically performs the necessary tasks without the need for elaborate positioning or size confirmation. The integrated camera supports not only scanning fixed patterns but also remotely monitoring the progress through the software.
300x510 mm Processing Area
With a product size of 97 x 56.5 x 23.4 cm and a net weight of 47 kg, this CO2 laser engraving machine boasts a processing area of 300x510 mm, allowing for the processing of larger objects. Simultaneous engraving or cutting of multiple parts enables efficient mass production.
Top-Level Safety Relays Certified by SGS
Our laser engraving machines use safety relays of the highest safety level. The safety relays are certified by the world's largest testing organization, SGS, and comply with the ISO 13849-1:2023 standard. The safety architecture and performance level meet PL e with Cat. 4.
2 Rotary Axes
The package includes two rotary axes, which allow for engraving on various cylinder or cone diameters. These rotary axes provide flexibility and enable smooth 360° rotation engravings on cylindrical and conical surfaces.
Polar Motor Focus
Precise adjustment for optimal sharpness and quality of laser engravings and cuts; time-saving through quick and easy focus adjustment; user-friendliness through simple operation via button press or control panel.
Compatible with Multiple Software
Polar uses industry-standard LightBurn layout, editing, and control software to connect directly to your laser without the need for additional software. (The LightBurn software should be ordered separately.)
laser class 1
Laser Class 1 and CE Compliant
Thanks to its closed construction, locking system, emergency stop button, key switch, monitoring of water flow, and other safety devices, the OMTech Polar Laser achieves Laser Class 1 for engraving on flat surfaces.
Technical Specifications
Product Information

Power Supply: 220-240V, 50Hz
Max. Engraving Speed: 500 mm/s
Focus Adjustment: Motor Focus
Controller: Ruida 6442S
Drive: Stepper Motor
Noise Level: 60-89 dB
Certification: CE
Bistable Safety Relay: Cat.4 PLe (EN 13849-1)
Package Dimensions (L×W×H): 1140x770x750 mm
Product Dimensions (L×W×H): 970x565x234 mm
Net Weight: 47 kg

About the Laser

Laser Type: CO2
Laser Power: 50W
Laser Wavelength: 10.6 μm
Max. Resolution: 1000 dpi
Engraving Accuracy: ±0.02 mm
Laser Tube Length: 900 mm
Laser Tube Diameter: 55 mm
Laser Tube Lifespan: 11,000 hours (<40% Power); 10,000 hours (40%–70% Power); 8,000 hours (>70% Power)

Working Area

Processing Area (LxW): 510x300 mm
Loading Area (LxW): 571x336 mm
Processing Table: Honeycomb Table
Max. Workpiece Height: 17 mm (standard); 51 mm (without honeycomb table)
Work Table Height Adjustment: Detaching and attaching the honeycomb table

Air and Water Cooling

Cooling Method of Laser Tube: Integrated Water Cooling
Water Flow Rate: Max. 9 L/min.
External Exhaust Fan Power: 60W
Exhaust Fan Airflow: 480 / 600 m³/hr. (two-stage)
Laser Head Air Assist Airflow: 533 L/min.

Integrated Camera

Max. Resolution: 5 MP
Field of View: 510×300 mm
Accuracy: ±1 mm

Rotary Axes

Number of Rotary Axes Supplied: 2
Suitable for Cone-Shaped Objects: Yes
Rotary Axis 1 (L × D): 0-240 × ϕ60-75 mm
Rotary Axis 2 (L × D): 0-240 × ϕ30-60 mm

Software and Connection

Included Operating Software: RDWorks (Windows)
Compatible Operating Software: LightBurn (Windows, MacOS), CADLaser, CorelLaser
Compatible Image Formats: .ai, .bmp, .dxf, .gif, .hpgl, .jpeg, .pdf, .plt, .png, .rd, .svg, .tiff, .tga
Connection/Transmission: WiFi, USB Cable, Ethernet Cable

Warranty

2-Year Overall Warranty, including 1-Year Warranty for Tube and Laser Power Supply

Package List

1 × Polar 50W Laser Engraver
2 × Rotary Axes
1 × Duct Fan with Remote Control
5 × Boards
5 × Cardboards
5 × Acrylic Boards
2 × USB Cables
1 × Ethernet Cable
2 × Pipes
3 × Pipe Clamps
1 × Allen Key Set
2 × Rulers
1 × Marker
2 × Accessory Boxes
1 × User Manual

Product Manual
Download PDF
Find your Match at OMTech
OMTech polar desktop CO2 laser engraver 50W CO2 Polar Desktop Laser Engraving Machine with 510x300 mm Engraving Area | OMTech Polar omtech 55w polar CO2 desktop laser engraver 55W CO2 Polar+ Desktop Laser Cutter and Engraver with 510x300 mm Engraving Area | OMTech Polar+
Materials that can be processed with a CO2 laser
Engraving Cutting
wood Wood
check check
Acrylic Acrylic
check check
Plastic Plastic
check check
MDF MDF
check check
Leather Leather
check check
Paper Paper
check check
Cardboard Cardboard
check check
Stone Stone
check check
Textile Textile
check check
Engraving Cutting
Rubber Rubber
check check
Foam Foam
check check
Glass Glass
check minus
Metal Coating Metal Coating
check minus
Stainless Steel Stainless Steel
minus minus
Aluminium Aluminum
minus minus
Titanium Titanium
minus minus
Silver Silver
minus minus
Gold Gold
minus minus
Engraving Cutting
wood Wood
check check
Acrylic Acrylic
check check
Plastic Plastic
check check
MDF MDF
check check
Leather Leather
check check
Paper Paper
check check
Cardboard Cardboard
check check
Stone Stone
check check
Textile Textile
check check
Rubber Rubber
check check
Foam Foam
check check
Glass Glass
check minus
Metal Coating Metal Coating
check minus
Stainless Steel Stainless Steel
minus minus
Aluminium Aluminum
minus minus
Titanium Titanium
minus minus
Silver Silver
minus minus
Gold Gold
minus minus
Customer inspiration gallery
Uwe Becker work
Uwe Becker work
Uwe Becker
Ursula van der Putten work
Ursula van der Putten work
Ursula van der Putten
Sven Witt work
Sven Witt work
Sven Witt
Dino Arcoraci work
Dino Arcoraci work
Dino Arcoraci
Carsten Freitag work
Carsten Freitag work
Carsten Freitag
Bernhard Haidenbauer work
Bernhard Haidenbauer work
Bernhard Haidenbauer
FAQ

The OMTech Polar laser cutter is designed for various materials, including wood, acrylic, leather, and glass, making it ideal for detailed laser engraving and cutting projects.

Yes, with its compact design, the Polar desktop laser cutter is perfect for small spaces while still offering powerful laser engraving and cutting capabilities.

Yes, this desktop laser engraver includes an integrated water cooling system to maintain optimal operating temperature, ensuring consistent performance and durability.

The Polar laser engraving machine is compatible with RDWorks software and LightBurn software, providing a user-friendly interface for precise control over engraving and cutting projects.
